Operating unit for amok alarm systems.
pending
The proX Keyswitch has a mechanical key switch and a proX1/proX2 reader integrated. The proX Key switch BUS-2 communicates with the corresponding intrusion detection system via BUS-2. All system data as well as all object-specific programming are realized with the programming software "WINFEM Advanced" or the programming software "IQ PanelControl" of the intruder alarm control panel. Voltage for the proX Key switch is supplied via the BUS-2 connection.
Use in amok alarm systems
The proX Key switch BUS-2 has been specifically designed as an amok alarm signalling device for use in schools, universities and other public buildings, for example. In the event of danger, it should be prompt and easy to trigger an amok alarm to contact emergency services (such as the police) with details such as "WHERE" (exact location), "WHEN" (time) and "WHO" (name of the person who triggered the alarm).
1. It must be so easy and safe to operate the device that it is practically impossible to trigger an alarm due to operating error.
2. All data required for quick intervention must be transmitted immediately to emergency services (e.g. the police).
3. Triggering of false alarms maliciously or accidentally must be prevented as far as possible.
The proX Key switch BUS-2 meets these requirements of the police.
Recommendation for the usage
Basically, the proX Key switch can be used with data carriers or keys. We strongly recommend the use of data carriers.
Only in that case can the parameter "WHO?" be sent.
Number of attachable proX Key switch devices:
561-MB24 16 proX Key switch devices
561-MB48 24 proX Key switch devices
561-MB100 (Index .10) 64 proX Key switch devices
MB-Secure up to 256 proX Key switch devices
Number of attachable data carriers:
561-MB24 32 Data carriers
561-MB48 128 Data carriers
561-MB100 (Index .10) 1024 Data carriers
MB-Secure up to 1024 Data carriers
Use in amok alarm systems
- Indication of operating state via green LED
- Unique identification when an alarm is triggered:
- "WHERE": e.g. address, building, floor, room number
- "WHEN": exact time at which the alarm was triggered
- "WHO": person who triggered the alarm (possible only when a data carrier is used)
- Installation possibility of a half cylinder as per DIN 18252
- Integrated reader for IK2/proX1 and IK3/proX2 ID data carriers
- Operation via half cylinder or ID data carriers
- Operation at BUS-2 of the 561-MB24 /48 /100 and MB-Secure intruder alarm control panel series
- Programming as integrated BUS-2 user with WINFEM Advanced or IQ PanelControl
- Simple administration of data carriers and authorizations using WINFEM Advanced or IQ PanelControl
- Cover and tear-off monitoring
| Operating voltage U_b |
12 V DC |
| Current consumption |
< 15 mA (mid.) |
| Detector group voltage |
8 V DC |
| Detector group end-of-line resistor |
12k1 ±40% |
| Detector group for tamper evaluation |
12k1 ±40% |
| Output for acoustical alarm signalling |
< 40 mA (active low) |
| Output for optical alarm signalling |
< 40 mA (active low) |
| Transponder reader |
IK2/proX1 and IK3/proX2 ID data carriers |
| Half cylinder as per DIN 18252 |
Standard dimension A = 30 mm, A = 35 mm possible |
| Operating temperature range |
-5 °C to +45 °C |
| Storage temperature range |
-25 °C to +70 °C |
| Type of protection EN 60529 |
IP40 |
| Environmental class as per VdS |
II |
| Dimensions (W x H x D) |
110 x 140 x 53 mm |
| Housing colour |
green (similar to RAL 6032) |
Required software versions:
The connection of the proX-key switch to an intrusion control panel require the software versions as follows:
Panel software: as of V11.xx (561-MB24 / MB48 / MB100 (MB100 with index .10)
WINFEM Advanced: as of V11.xx
Without Half cylinder.
028032 Half cylinder
